Accent is a family of luminaires designed to optimise visual comfort when illuminating either objects or space, and is supported by a series of facades and integration systems to ensure a consistent visual language between the luminaire and the surrounding architecture. An adjustable depth mechanism allows the optical source to be moved to a shallower position for extra wide or ellipitcal illumination, or to be fixed in a deeper position for use with narrower beams and accent lighting. A range of light shaping accessories allows the user to customise the lighting technique, from even diffuse light to oval beams for a wide range of applications.
High pressure die cast black anodised ceiling mount with stainless steel fixing blades; black anodised die cast retention mechanism for optical assembly; brass thumbscrew module fixation. Optical unit set back with variable 45mm depth tolerance. Optional internal snoot in black anodised die cast aluminium. Facades in high pressure die cast aluminium; powdercoat finish. IP facade with clear lens and silicon seal. Optical housing and dissipation system in black anodised forged aluminium with 2 pole connector to secondary terminal on LED power supply 180mA or 350mA constant current. Primary terminal with plug and flex; active power factor correction; current regulation, voltage spike protection. Class III. IP20 — IP44.
Rotationally symmetrical polished faceted reflector; COB LED; <2 SCDM; L90 B10 50 000hr; Ra98; R1=99 R2=100 R3=97 R4=100 R5=99 R6=98 R7=98 R8=97 R9=92 R10=98 R11=97 R12=87 R13=99 R14=97 R15=99; TM30 = R95 F103. In combination with optional spreader, linear spreader, di!user lens or honeycomb louvre.
Specifications
Accent 100
- Location:Indoor/ Outdoor
- Optics:25° / 40° / 60°
- Colour Temperature:2700K / 3000K / 4000K / 2700-1800K
- CRI:Ra97 / Ra90
- TM30:Rf95 Rg103
- Chromacity:<2 MacAdam Step Ellipse
- Lumen Maintenance:L90 B10 50000hrs
- Power:8W / 7W / 14W
- Current:180mA / 350mA
- Voltage AC:240V-AC
- Control:Remote Fixed Output / Phase DIM / DALI
- Articulation:Fixed / Directional / Asymmetrical
- Ingress Protection:IP20
